OVERVIEW

• High performance 1 x 15″ subwoofer
• Operation with K&F SystemAmps
• Frequency response 33 Hz (-10 dB)
• Maximum sound pressure level of 136 dB (SPL peak/1 m/half space)

TECHNICAL DATA

Design

Bass reflex system

Operation with K&F PLM+ Series, K&F D Series

Lower cut-off frequency

33 Hz (-10 dB)
38 Hz (-3 dB)

Coverage Omnidirectional (a cluster of 3 or in combination with K&F NOMOS LT can be driven in cardioid)

Power handling nominal 750 watts

Power handling program 1.500 watts

Power handling peak 3.000 watts

Max. SPL 136 dB (SPL peak/1 m/half space)

Impedance nominal 8 Ω

Components

15“ subwooferchassis, 57 mm peak-topeak excursion, inside and outside ventilated voice coil gap for reduced power compression, aluminium demodulating ring for very low distortion

Connectors

2 x speakON® 4-pol NLT4MP (+1/-1) (back)
1 x speakON® 4-pol NLT4MP (+1/-1) (front)
IN parallel to OUT

Enclosure

15 mm birch multiplex with highly resilient Polyurea synthetic coating in RAL 9005 (black), 8 ergonomical butterfly handles, 8 non-abrasive plastic sliders, 8 stacking grooves for save stacking of NOMOS LS II, NOMOS LT and Line 212, 2 locking profiles for optional transport cover with 4 x 100 mm transport castors, additional speakON®-connector hidden behind the rotatable logo on the front grille, ballproof steel grille with black acoustic foam behind the grille

Dimensions (W x H x D)

541 x 471 x 640 mm

Weight

30.3 kg
